Description
The i-m4 Roadster is kitted out with front and rear LED lights and indicators enabling you to drive your i-m4 Roadster on or off the course, which comes in handy if you live close to your course.
Body & Chassis
- Front and rear headlights
- Front and rear indicator lights
- Steel frame construction
- Strong fibreglass body
- Rust protected powder coated steel work
- Easy battery access
- Range of colours available
Power
- Motor 36V 1300-watt permanent magnetism
- X 1 50AH 37V Lithium battery
- Automatic pulse charger Input AC110V/220V
- Throttle mounted speed switch High (19Km/h) Low (6.4Km/h)
- Recharge time 3-4 hours
- Maximum travel distance 50Km
- Curtis Controller 1226-3402 DC36V/160A
- Curtis Connector – Throttle controlled
- Hall accelerator continuous variable speed system
Dimensions
- Length 49.5” (127.7cm)
- Width 32.5” (82.6cm)
- Height 42” (106.7cm)
- Height folded 31” (78.7cm)
- With quick seat release seat system 25” (635cm), 27” (685cm) or 29” (736cm)
- Minimal ground clearance 4.5” (11cm)
Performance
- One person seating capacity
- Carrying capacity 200kg
- Weight 100kg with batteries, 85kg without batteries
- Maximum speed 12-19km/h
- Slope climbing capacity 30 degrees
- Turning radius adjustable up to < 3m
- Forward & reverse console mounted
Other features
- Helix spring shock absorbers
- Tyres: 32.5cm x 15cm 4 ply tyres
- Japanese wheel bearings
- Electromagnetic braking system
- Full range of optional accessories available
Part exchange available – contact us
